Specification：

Charging Current: 4.0A

Battery Voltage: 6V/12V

12V STD/12V LFP/12V AGM:4A

6V STD:2A

Maintain :1A

Recond:16.5V/1.5A

Re-BMS for LFP

Votage test function

Supply:3A

Winter:Auto

Power: 70W

Voltage  AC: 220-240VAC,50-60HZ

Charging type: 6-Steps,Fully automatic

Cable Length: 1.5M

Battery Capacity: 1.2-85Ah，up to 150Ah for Maintenance.

Insulation class : IP65

Indication: LCD

Battery Type : All type 6V/12V Lead-Acid Battery  & LiFePO4  Battery with BMS

Highlights：

1)  10 Charging modes:12V STD,12V LFP,12V AGM,6V STD,Maintain,Recond Re-BMS,Voltage test,Supply,Winter(Auto)

2) 12V STD for standard lead-acid batteries.

3) 12V LFP for 12V LiFePO4 batteries.

4) 12V AGM for 12V AGM batteries.

5) 6V STD for 6V Standard lead-acid batteries.

6) 12V Maintain :Charge 12V lead-acid batteries with a smart charging current.Mainly for Maintenance purpose

7) 12V RECOND:Recondition mode for old damaged batteries.

8)Winter Mode(Auto):Special charging mode design for Winter, when surrounding ambient temperature is lower than 5°C, winter mode will be Activated automatically.

8) Re-BMS: Available start  LiFePO4 battery protected by BMS system

9) With battery voltage test function

10) Supply:used to retain a vehicle’s on-board computer settings during battery repair or replacement.

11)Indicate the charging current and voltage.(Amp/Voltage )

12) Design with Large Hook for easy use

13) Wall hanging design by powerful Magnet

14) With Touching Switch button
